Specifications

Current rating: 15A AC/DC Max. (14 AWG)

Voltage Range: 300V AC,DC

Withstand Voltage: 1500V AC/Minute

Contact Resistance: 10 mΩ Max.

Insulation Resistance: 100 MΩ Min.

Temperature Range: -40℃ to 105℃

Reference

Mates with 66773M Type-2 / Type-4 Series Receptacle Housing

Material: Heat Nylon 94V-0, Light Ivory color (Natural)

Use with 66773T / 66774T Series Terminal

Use with 66773A Type-2 /Type-4 ,Series Retainer
