Specifications

Current rating: 16A Max. (AWG 14)

Voltage Range: 250V AC,DC

Withstand Voltage: 1000V AC/Minute

Insulation Resistance: 1000 MΩ Min.

Contact Resistance: 5 mΩ Max. before environment test

Temperature Range: -25℃ to 85℃

Accept Wire Size AWG 14 to AWG 22

Reference

Mates with 3301T, 3302T Terminal

Accept 66101T Series Terminal
