Specifications

Current rating: 16A (AWG 14)

Voltage Range: 250V AC,DC

Withstand Voltage: 2000V AC/Minute

Insulation Resistance: 1000 MΩ Min.

Contact Resistance: 5 mΩ Max. before environment test

Temperature Range: -40℃ to 105℃

Accept Wire Size: AWG 10 to AWG 20

Reference

Mates with 3301T, 3302T Terminal
