Current rating: 19A AC/DC (AWG 16)

Voltage Range: 12V AC,DC

Withstand Voltage: 1800V AC/Minute

Insulation Resistance: 1000 MΩ Min.

Contact Resistance: 10 mΩ Max.

Temperature Range: -30℃ to 105℃

Wire Range: AWG 18 to AWG 22

Reference

Use with 66502T021R Terminal

Mates with 6506M Receptacle Housing
