Specifications

Current rating: 5A AC/DC Max. (AWG 20)

Voltage Range: 300V AC,DC

Withstand Voltage: 1500V AC/Minute

Insulation Resistance: 1000 MΩ Min.

Contact Resistance: 10 mΩ Max. before environment test

Temperature Range: -40℃ to 100℃

Applicable Wire: AWG 16 to AWG 22

Applicable PC Board Thickness: 1.6mm

Reference

Mates with 3969T Board-in Terminal
