Specifications

.Current rating: 1A AC,DC Max. (AWG 26)

.Voltage Range: 125V AC,DC

.Withstand Voltage: 250V AC/Minute

.Contact Resistance: 20 mΩ Max. before Environment test

.Insulation Resistance: 100 MΩ Min.

.Temperature Range: -40℃ to 85℃

Reference

.Mates with 1251P,1252P Headers

.Use with 1253T Terminal
