Specifications

Current rating: 3A AC/DC Max.

Voltage Range: 250V AC,DC

Withstand Voltage: 500V AC/Minute

Contact Resistance: 20 mΩ Max. before environment test

Insulation Resistance: 1000 MΩ Min.

Temperature Range: -40℃ to 105℃

Applicable PC Board Thickness: 1.6mm

Reference

Mates with 7302P IDC Plug Housing
