Specifications

Current rating: 4.0A (AWG 22), 12A (AWG 16), 16.0A (AWG 14)

Voltage Range: 600V AC,DC

Withstand Voltage: 2500V AC/Minute

Insulation Resistance: 5000 MΩ Min.

Contact Resistance: 25 mΩ Max. before environment test

Temperature Range: -40℃ to 105℃

Reference

Mates with 66015S Housing

Applicable P.C. Board Thickness: 1.6 mm
