Specifications

Current rating: 10A AC/DC Max. (16 AWG, 2-Circuit)

Voltage Range: 300V AC,DC

Withstand Voltage: 1500V AC/Minute

Contact Resistance: 7 mΩ Max.

Insulation Resistance: 1000 MΩ Min.

Temperature Range: -25℃ to 90℃

Reference

Mates with 4500F Plug Housing

Use with 4500TM Terminal and , 4500A Series T.P.A
