Specifications

Current rating: 2A AC,DC Max. (AWG 24)

Voltage Range: 250V AC,DC

Withstand Voltage: 800V AC/Minute

Contact Resistance: 10 mΩ Max. before Environment test

Insulation Resistance: 1000 MΩ Min.

Temperature Range: -25℃ to 85℃

Reference

Use with 2008S Board-in Housing
